SystemSculpt AI

SystemSculpt AI (Obsidian Plugin)

SystemSculpt AI adds AI chat, meeting transcription, semantic search, and agent workflows inside your Obsidian vault. Bring your own API keys or use managed models.

Current release facts

• Plugin version: 5.9.0
• Minimum Obsidian version: 1.4.0
• Platforms: desktop and mobile (manifest.json sets isDesktopOnly: false)
• License: MIT

What you can do

• Chat with your notes through SystemSculpt.
• Toggle agent mode on/off to switch between tool-assisted and pure reasoning chat.
• Select custom system prompts from vault markdown files per conversation.
• Use built-in vault tools to read, search, edit, move, and organize notes.
• Filter models by favorites in the model selection modal.
• Bring your own Claude (Anthropic) and Gemini (Google) keys with native API support, alongside OpenAI, xAI, and OpenRouter.
• Run entirely on your own provider key — BYOK chat never hits a SystemSculpt license wall.
• Set up local Pi providers from the Providers tab, including clearer Ollama guidance.
• Use the redesigned Studio canvas foundation for much larger graph workspaces.
• Generate images from a Studio image node: pick the model, aspect ratio, image size, seed, and batch count.
• Recover from streaming failures with clearer chat error notices and disconnect controls.
• Find semantically similar notes with embeddings, backed by a portable index that survives Obsidian Sync and vault restore.
• Record audio and transcribe notes, including self-hosted Whisper and a separate post-processing model.
• Run capture-folder workflow automations.

Quick start

1. Install SystemSculpt AI from Obsidian Community Plugins (or use manual install below).
2. Open Settings -> SystemSculpt AI -> Account.
3. Activate your SystemSculpt license key.
4. Run the command Open SystemSculpt Chat.
5. Optional: enable embeddings in Knowledge for Similar Notes.

Installation

Community Plugins (recommended)

1. Open Obsidian Settings -> Community plugins.
2. Search for SystemSculpt AI.
3. Click Install, then Enable.

Manual install

cd /path/to/vault/.obsidian/plugins/
git clone https://github.com/systemsculpt/obsidian-systemsculpt-ai systemsculpt-ai
cd systemsculpt-ai
npm install
npm run build

Core docs

• Docs hub: docs/README.md
• Getting started: docs/user/getting-started.md
• Settings reference: docs/user/settings.md
• Commands: docs/user/commands.md
• Ribbon icons: docs/user/ribbon-icons.md
• Similar Notes: docs/user/similar-notes.md
• Audio & transcription: docs/user/audio-transcription.md
• Automations: docs/user/automations.md
• Troubleshooting: docs/user/troubleshooting.md

Development

Build and checks

npm run dev               # watch build
npm run build             # production build
npm run check:plugin      # typecheck + bundle resolution
npm run check:plugin:fast # faster local check
npm run check:all         # plugin check + Jest suite

If you keep a local-only systemsculpt-sync.config.json, the dev watcher now auto-syncs every successful rebuild into all configured pluginTargets plus any mirrorTargets, including remote Windows SSH mirrors declared as "type": "windows-ssh". ./run.sh --headless remains the canonical background entrypoint because it enables the same build-integrated sync path and also asks the already-open desktop vault to hot-reload the plugin after local sync succeeds.

Tests

npm test
npm run test:debug
npm run test:strict
npm run test:embeddings
npm run test:leaks
npm run test:native:desktop:extended
npm run test:native:android:extended
npm run check:pre-push              # full native gate (unit + build + Android + Windows)
npm run check:pre-push:quick        # fast gate (unit + build only)

Testing architecture docs:

• testing/README.md
• testing/native/README.md

Desktop validation is attach-only to an already-open Obsidian vault. Keep live sync running with ./run.sh --headless and use the desktop bridge runner when you need real chat/model verification without taking focus.

Local plugin release

npm run check:release:windows         # require the GitHub Windows E2E check on the current commit
npm run check:release:windows:local   # optional maintained Windows host/dev helper
npm run check:release:native          # required native release matrix
npm run check:release-surfaces -- --version <version> --require-notes
npm run release:plugin                  # auto bump (major/minor/patch from commits)
npm run release:plugin -- --dry-run    # preview next version + notes only
npm run release:plugin -- --bump patch # force a specific bump

Release automation now runs fully on your local machine: it validates the plugin, builds the release bundle, commits the version bump, pushes main and the tag, and creates a draft GitHub release with gh. Before it tags anything, the release script now runs a safety preflight that blocks tracked local-only files, unignored local-only files that should probably go into .gitignore, hardcoded local paths, hardcoded desktop vault selectors, and secret-looking tokens. If GITHUB_TOKEN or GH_TOKEN is present but weaker than your stored gh login, the release script now automatically falls back to the stored auth for push and draft-release steps. The native release matrix is now explicit instead of implicit: macOS desktop baselines, the GitHub Windows E2E check, and Android runtime smoke must all pass before release creation can continue. The Windows E2E check runs a fresh Obsidian install, clean-install parity, and desktop baselines on windows-latest for the exact commit being released. iOS runtime smoke is included automatically when a paired physical device is available on the host and is otherwise skipped honestly. Use npm run check:release:windows:local only when you want the optional Windows-only dev helper on a maintained Windows host before waiting on the canonical GitHub check.

The old tag-triggered GitHub Actions release workflow is retired. Treat npm run release:plugin as the canonical publish path for this repo. That release path now packages the standard Obsidian plugin artifact set only: manifest.json, main.js, and styles.css. Before release, npm run check:release-surfaces -- --version <version> --require-notes verifies the exact version surfaces and release notes file. After a production build, add --check-artifacts to verify the release asset set too. Desktop validation is now bridge-based and no-focus by default; the old renderer-driving desktop lane is retired. When multiple synced desktop vaults exist, use --vault-name <vault-name> or --vault-path <absolute-path> to pin one explicitly. Otherwise the desktop runner prefers the latest live bridge target automatically.

Canonical source files for docs

These files define the user-facing surfaces and are the source of truth:

• Settings tabs: src/settings/SettingsTabRegistry.ts
• Commands: src/core/plugin/commands.ts, src/main.ts
• Ribbon icons: src/core/plugin/ribbons.ts
• Filesystem MCP tools: src/mcp-tools/filesystem/toolDefinitions/*.ts
• YouTube MCP tool: src/mcp-tools/youtube/MCPYouTubeServer.ts
• Web research tools: src/services/web/registerWebResearchTools.ts

Support

• Website: https://systemsculpt.com
• Repo: https://github.com/SystemSculpt/obsidian-systemsculpt-ai
• Issues: https://github.com/SystemSculpt/obsidian-systemsculpt-ai/issues
• Email: [email protected]

License

MIT. See LICENSE.
