Understory

Understory

Chinese README | Website | Privacy

Understory is a local-first knowledge layer for Obsidian. It builds a private maintenance layer under your vault, driven by Vector, ER, and Graph analysis, so related notes, claims, concepts, conflicts, and orphan pages can be discovered and maintained over time.

The plugin is desktop-only and works with the local Understory engine. It is designed for people who want Obsidian to keep a durable, self-refreshing memory layer without sending vault data to a developer-operated service.

What It Does

• Shows related-note suggestions in the right sidebar through Show Understory.
• Discovers note relationships with hybrid signals, including local structure, entity facts, graph analysis, and optional model-powered semantic signals.
• Flags possible conflicts, stale notes, orphan pages, and broken knowledge paths.
• Maintains local reports and caches in .understory.
• Supports English and Chinese UI text from the plugin settings.
• Lets you choose a privacy mode before configuring any model provider.

Privacy Modes

Understory starts local-first.

Optional cloud features can use OpenAI, Zhipu, or a custom OpenAI-compatible endpoint. You provide your own API keys. Bondie Labs does not receive or manage your notes, prompts, embeddings, responses, logs, or API keys.

Plugin logs and short diagnostics redact known API keys, bearer tokens, webhook URLs, and similar secrets. Raw process stdout is not stored in plugin logs by default.

Payment status: Optional payments. The plugin is free to install. Local mode does not require an API key. Provider accounts, API keys, pricing, quotas, privacy terms, and billing are controlled by the provider you choose.

Requirements

• Obsidian desktop app.
• The local Understory engine.
• Python available on your machine.

The plugin is marked isDesktopOnly because it uses local files, Node APIs, and a Python subprocess.

Manual Install

Until the plugin is accepted into the Obsidian Community directory, install it manually from the latest GitHub release.

1. Download these release assets:

   • manifest.json
   • main.js
   • styles.css

2. Create this folder in your vault:

   <Your Vault>/.obsidian/plugins/understory/


3. Put the three downloaded files into that folder.

4. Restart Obsidian.

5. Enable Understory in Settings -> Community plugins.

Engine Setup

Understory for Obsidian is the plugin shell. The local engine is maintained separately:

git clone https://github.com/fyaic/Understory-graphify-engine.git
cd Understory-graphify-engine
python -m pip install -r requirements.txt

Set the engine path before launching Obsidian:

$env:UNDERSTORY_ENGINE_DIR="C:\path\to\Understory-graphify-engine"
$env:UNDERSTORY_PYTHON_PATH="python"

You can also set the engine folder and Python path inside the Understory settings page. After changing system environment variables, restart Obsidian so the desktop app can read them.

The Check setup button now opens a local diagnostic panel. It shows the plugin version, engine version or git commit, Python version, selected paths, required engine scripts, Python dependency checks, vault .understory deployment status, and permission issues. Each problem includes a suggested fix and, when useful, a command you can copy. The panel does not run pip install, git pull, or other repair commands automatically.

Common manual fixes:

python -m pip install -r "C:\path\to\Understory-graphify-engine\requirements.txt"
$env:UNDERSTORY_ENGINE_DIR="C:\path\to\Understory-graphify-engine"
$env:UNDERSTORY_PYTHON_PATH="python"

Use Copy diagnostics when you need to share setup details with a maintainer. The copied summary is designed to exclude API keys, webhook URLs, and vault note content.

First Run

1. Open Settings -> Understory.
2. Click Check setup to confirm the local engine, Python, scripts, dependencies, vault deployment, and permissions are available.
3. Keep Network mode on Local only, or explicitly choose a cloud mode and configure your own provider key.
4. Open the command palette and run Show Understory.

Agent API

Understory also exposes a local Agent API for automation. It is not an HTTP server and does not open a port. Agents can call it through a JSON CLI or an MCP stdio server:

node scripts/understory-agent-cli.js status --vault "C:\path\to\vault" --json
node scripts/understory-agent-cli.js get-relations --vault "C:\path\to\vault" --note "Notes/A.md" --json
node scripts/understory-agent-cli.js refresh-relations --vault "C:\path\to\vault" --note "Notes/A.md" --engine-dir "C:\path\to\Understory-graphify-engine" --json
node scripts/understory-agent-cli.js insert-relation --vault "C:\path\to\vault" --note "Notes/A.md" --target "Notes/B.md" --title "B" --json

MCP configuration example:

{
  "mcpServers": {
    "understory": {
      "command": "node",
      "args": [
        "<path-to-repo>/scripts/understory-mcp-server.js",
        "--vault",
        "C:/path/to/vault",
        "--engine-dir",
        "C:/path/to/Understory-graphify-engine"
      ]
    }
  }
}

All Agent API responses use a JSON envelope with ok, data, error, and meta. The API keeps paths inside the selected vault, does not return full note bodies by default, and reuses Understory secret redaction. See docs/AGENT_API.md for the full tool contract.

Build From Source

This repository keeps the reviewable plugin source in src/ and the Obsidian release files at the repository root.

npm run build
npm run check

The build script bundles src/*.js into root main.js.

Release Files

Each GitHub release must attach:

• manifest.json
• main.js
• styles.css

The release tag must match manifest.json version exactly, for example 1.7.2.

Links

• Website: https://bondie.io/research/understory
• Core engine: https://github.com/fyaic/Understory-graphify-engine
• Privacy: PRIVACY.md
