Checklist Progress Bar

by Adam Tweedie
5
4
3
2
1
Score: 52/100

Description

Displays a progress bar for your checklist items

Reviews

No reviews yet.

Stats

3
stars
2,175
downloads
0
forks
168
days
2
days
2
days
7
total PRs
0
open PRs
0
closed PRs
7
merged PRs
1
total issues
0
open issues
1
closed issues
31
commits

Latest Version

2 days ago

Changelog

1.1.1

Fixed

  • The page no longer jumps to the text cursor when you check or uncheck an item. Each progress bar update scrolled the cursor into view. The plugin now updates the bar without a scroll.

README file from

Github

Checklist Progress Bar

Automatically display a live progress bar above any checklist block in your Obsidian notes.


How It Works

Place a > [!progress] callout directly above a checklist block. The plugin will automatically calculate how many items are checked and update the progress bar in real time as you tick things off.

> [!progress] ███████████░░░░░░░░░ 9/16 (56%)

- [x] Set up project repository
- [x] Define initial requirements
- [ ] Design system architecture
- [ ] Implement core data models
...

No configuration needed — just drop in the callout and start checking things off.


Usage

  1. Open any note with a checklist
  2. Add the following line directly above your list:
> [!progress]
  1. The progress bar updates automatically as you check and uncheck items

Note: The > [!progress] line must appear directly before your checklist block. Items are counted from that line down to the next progress bar or end of file.


Colours

Add an optional two letter colour code after progress to change the accent colour of the bar.

> [!progress]     ← default (purple)
> [!progress bl]  ← blue
> [!progress pi]  ← pink

Available colours

Code Colour Code Colour Code Colour
bl Blue li Lime ma Magenta
cy Cyan ye Yellow pu Purple
te Teal am Amber in Indigo
gr Green or Orange br Brown
re Red pi Pink gy Grey

Settings

Open Settings → Checklist Progress Bar to configure the plugin.

Counter style

Controls how the item counts are shown after the bar. By default the bar shows a fraction of checked items. If you prefer to see the open and done counts spelled out, pick one of the other styles:

Style Example
Fraction (default) ████████░░░░░░░░░░░░ 4/10 (40%)
Open and done ████████░░░░░░░░░░░░ 6 open · 4 done (40%)
Both ████████░░░░░░░░░░░░ 4/10 · 6 open (40%)

The setting applies to every progress bar in your vault. The note you have open updates immediately when you change it. Other notes update the next time they are edited.


Features

  • Live updates on every keystroke — no need to reload or save
  • Keeps your scroll position, cursor and undo history when a bar updates
  • Optional colour codes, 15 colours to choose from
  • Choice of fraction or open/done counters
  • Supports nested checklist items at any indentation level
  • Multiple progress bars per note, each tracking its own block and colour
  • Clean callout styling with both dark and light theme support
  • Zero configuration required, with an optional counter style setting

Installation

  1. Open Obsidian and go to Settings → Community Plugins
  2. Search for Checklist Progress Bar
  3. Click Install, then Enable

Manual

  1. Download the latest release from GitHub Releases
  2. Copy main.js, manifest.json, and styles.css into your vault at:
    <vault>/.obsidian/plugins/checklist-progress-bar/

  3. Restart Obsidian and enable the plugin under Settings → Community Plugins

Compatibility

  • Obsidian v1.0.0 and above
  • Works in both Live Preview and Reading mode

Feedback & Contributions

Found a bug or have a feature request? Open an issue on GitHub. Pull requests are welcome.
